High-Precision Electric Torque Sensor for Drilling & Industrial Automation | CNPS

The sensor measures torque continuously in both static and dynamic applications, converting mechanical torque loading into stable electrical signals. CNPS rotational torque sensor models are specifically designed for dynamic shaft measurement, supporting rotational speeds up to 50,000 rpm. Signal conditioning provides true RMS measurement with wide bandwidth and AC/DC compatibility, and the result is delivered through voltage, current, USB or CAN bus outputs for real-time monitoring and process control.

• High accuracy up to ±0.05% FS — Provides trustworthy torque data for quality control and process optimization decisions.
• Wide torque coverage from micro loads to heavy industrial torque — One platform spans laboratory testing and high-load mechanical applications; confirm the exact range by model.
• Rotational speed up to 50,000 rpm — Enables accurate dynamic torque measurement on high-speed rotating shafts.
• Multiple outputs: voltage, current, USB, CAN bus — Plug-and-play compatibility with modern test benches, production lines, and automation systems.
• Sturdy stainless steel casing with IP65 protection — Withstands mud, dust, and drilling vibrations in the field.
• Overload capacity up to 200% FS — Protects the sensor against overload conditions and extends service life.
• Clamp design for quick installation — Sensor modifications can be made without stopping the machine, minimizing production downtime.
• Intrinsically safe model complies with EX/EN safety requirements — Suitable for hazardous-area installations where safety compliance is required.

Summary: The CNPS electric torque sensor is mounted onto the shaft or drive train using a clamp design, so it can be fitted or modified without stopping the machine. It captures torque loading in static and rotating shafts and converts it into a stable electrical signal for continuous monitoring.

Steps

• Clamp the sensor onto the shaft or structure without interrupting machine operation.
• The sensor captures torque loading in static and rotating shafts, with true RMS measurement across a wide bandwidth and AC/DC compatibility.
• On-board signal conditioning converts the mechanical loading into a stable electrical signal.
• Real-time torque data is delivered via voltage, current, USB or CAN bus outputs to test benches, production lines, or automation systems.
• Operators use the continuous torque data to reduce drilling risks, enhance operational efficiency, and support quality control.

• Automotive, robotics, aerospace, and manufacturing — Precision torque monitoring for assembly, test, and production processes.
• Laboratory testing and high-load mechanical applications — From micro-load research setups to heavy industrial torque measurement.
• On-site mud logging and drilling operations — Real-time torque data reduces drilling risks and enhances operational efficiency in harsh rig environments.
• Modern test benches and production lines — Plug-and-play compatibility with voltage, current, USB or CAN bus outputs.
• Rotational (dynamic) shaft measurement — Rotational torque sensor models specifically designed for dynamic shaft applications.

The sensor connects seamlessly to automation systems through voltage, current, USB or CAN bus outputs, providing plug-and-play compatibility with modern test benches and production lines. Multiple protocol outputs allow the same sensor platform to feed data acquisition systems, control panels, and drilling or mud logging equipment without additional signal converters.

• A decade of precision-instrument experience — CNPS has over a decade of experience providing precision instruments for oil and gas and mud logging operations.
• Quality-verified supply chain — Electric torque sensor solutions feature an ISO-9001 certified supply chain, rigorous internal testing, and third-party validation.
• Built for harsh field conditions — Each sensor withstands temperature fluctuations, high currents, overload conditions, and harsh on-site environments.
• Long service life, minimal maintenance — With proper usage, the sensor has a very long service life and requires almost no maintenance, plus complete system support including glass fiber and composite solutions.
