Mud Logging Unit - Real-Time Drilling Data & Monitoring System | CNPS

• Sensor & acquisition layer — Input channels that receive signals from mud logging sensors such as mud density, mud conductivity and pressure sensors. Channel count, sensor set and supported signal types are confirmed per project.
• Processing & data logging core — Central unit that processes incoming data and maintains time-stamped records. Hardware platform, processing scope and logging capacity are confirmed per project.
• Monitoring & display station — Operator interface for live data display and monitoring. Screen layout, parameter list and HMI design are confirmed per project.
• Safety & formation gas monitoring — Monitoring channels dedicated to drilling safety and formation gas parameters. Detection scope and alarm thresholds are confirmed per project.
• Alarm & event system — Alarm handling, event logging and notification logic, configured per project.
• Communication & data output — Data export and connectivity, including protocols and remote access. Interface types are confirmed per project.
• Power & enclosure — Power supply and enclosure design matched to the installation site, including indoor/outdoor and hazardous-area requirements. Confirmed per project.

• Real-time drilling data monitoring
• Drilling safety monitoring
• Formation gas monitoring
• Time-stamped data recording
• Sensor integration
• Alarm and event handling
• Reporting and data export
• Remote monitoring readiness

• Sensors — CNPS mud logging sensors (mud density, mud conductivity, pressure and related instruments) and any project-defined third-party sensors provide process signals. Sensor set and signal types are confirmed per project.
• Acquisition — The unit's acquisition layer receives and conditions the incoming signals. Channel configuration is confirmed per project.
• Processing & logging — Data is processed and stored as time-stamped records. Processing scope and storage capacity are configured per project.
• Display & monitoring — Operators view real-time data and monitored parameters on the unit's display station. Layout and parameter set are confirmed per project.
• Alarms & reports — Threshold alarms, event logs and project-defined reports keep drilling teams informed of safety and formation gas conditions.

• Drilling operations where real-time drilling data supports day-to-day decision making.
• Operations requiring continuous monitoring of drilling safety and formation gas conditions.
• Well projects that integrate CNPS mud logging sensors (mud density, mud conductivity, pressure) into a single monitoring platform.
• Onshore and offshore environments - suitability and enclosure requirements are confirmed per project.
• Exploration and development wells where a unified, configurable logging platform is preferred.

Summary: The Mud Logging Unit is built around continuous monitoring. Monitored parameters, display priorities and alarm thresholds are agreed with the customer so the system answers the specific questions of each drilling program.

Points

• Live data display configured per project
• Alarm and event log for abnormal conditions
• Time-stamped records for post-run analysis
• Data export and reporting in project-defined formats
• Remote viewing where required by the project network design

• Requirements definition — CNPS and the customer define the monitoring scope, parameter list and site conditions.
• Sensor & channel configuration — Input sensors (CNPS mud logging sensor family and/or third-party) and channel mapping are agreed.
• Interface confirmation — Communication protocols, data formats and remote access requirements are confirmed.
• Enclosure & environment — Power, mounting and protection requirements are matched to the installation site.
• Calibration & acceptance — Monitoring thresholds and recording settings are set, and acceptance testing is performed.
• Delivery & commissioning — The unit is delivered, installed and commissioned with project-specific documentation and training.

• Integrated sensor ecosystem — CNPS designs and supplies the mud logging sensor family (mud density, mud conductivity, pressure, temperature, level, torque) documented for integration with mud logging instruments, so the unit and its sensors can come from one source.
• Engineered for oilfield environments — CNPS mud logging sensors are designed to withstand extreme oilfield environments (per CNPS sensor documentation), keeping monitoring reliable where drilling conditions are toughest.
• Project-specific configuration — No off-the-shelf assumptions: every unit, from channel count to alarm logic, is defined to the project's requirements, with unconfirmed parameters clearly marked until agreed.
• Support from configuration to commissioning — CNPS works through requirements, configuration, acceptance and commissioning with the customer, and remains available for after-sales support of the delivered system.
